The DataSwatch™ inbuilt virtual colour library for Robe LED fixtures provides consistent colour rendering with commonly matched filter ranges, allowing for rapid and accurate programming.

RLCT™ – Robe lens coating technology

Just like with spectacles, our lens coating technology protects soft plastic lenses against surface scratches, that can even occur during cleaning when scrubbed repeatedly. Anti-static properties prevent dust build-up on the lenses, thus extending the period between maintenance cleaning.

L3™ – Low Light Linearity System

The L3™ Low Light Linearity System produces imperceptible, ultra-smooth fades to black.

GDTF – General Device Type Format

The General Device Type Format creates a unified definition for exchange of data for the operation of intelligent luminaries, such as moving lights. The file format is human readable and developed using open source formats.

Tungsten Emulation

When selected, the luminaire will mimic the colour temperature of a tungsten lamp as you lower the output to produce that classic warm glow.

FW diffusers for pixelated washers

Robe fixtures homogenise beams really well but, for the ultimate smoothness, most of our pixelated LED wash lights can easily be fitted with a Fresnel Wash (FW) diffusion filter in-between the LED array and the lenses. They can also be ordered pre-installed if desired, as FW versions.

REAP™ – Robe Ethernet Access Portal

The Robe Ethernet Access Portal allows to access internal data from a networked fixture, viewed as a web page, addressable via the fixtures network IP.

Epass™

Robe lighting’s Epass™ provides Ethernet in/out connections with a pass-through switch that sustains Ethernet integrity when the fixture has no power to automatically maintain network connectivity.

Cpulse™ – Pulse Width Modulation Control

Cpulse™ is a PWM (Pulse Width Modulation) control system for luminaires that allows you to select and fine-tune the LED driving frequency, from either the fixture's onboard display or remotely via DMX. By frequency manipulation in a range from 800 Hz to 25 kH, you ensure no flicker will be visible on any camera system including the latest HD & UHD models, ready for 8K and 16K. This means our fixtures can be used with all the latest cameras types for TV, video and film applications.

Downloads

Find and download all technical and marketing documents related to this product.

Technical Specification

Expand AllCollapse All

Source

Optical system

Dynamic Effects and Features

Control and programming

Movement

Thermal specification

Electrical specification and connections

Approvals

Mechanical specification

Rigging

Included items

Optional accessories

Legal
